Technical Specifications:
| Wire diameter | 6-16 mm |
| Max.bending angle | 150 |
| Max.length of stirrup side | 700 mm |
| Min length of stirrup side | 40 mm |
| Traction speed | 90 m/min |
| Max. bending speed | 60 rpm |
| Length accuracy | ±1 |
| Bending angle accuracy | ±1 |
| Average electric consumption | 2 kw |
| Installed power | 4 hp |
| Wire production capacity | 60 m/min |
| Bending direction | Bi-direction |
| Twist prevention system | Available |
